YK-280S Fingerless Type Single Facer For 2 Ply Corrugated Cardboard Production Line

Name: YK280S Fingerless Type Single Facer For 2 Ply Corrugated Cardboard Production Line
Brand: YIKE GROUP
Price: 1 USD

Brand Name : YIKE GROUP

Model Number : YK-280S

Certification : ISO,CE

Place of Origin : CHINA

MOQ : 1 Set Single Facer

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50 Sets Per Month

Delivery Time : 30 Days After Deposit of Single Facer

Packaging Details : Plastic Film,FCL

Packaging type : Cartons,Case,Film

Warranty : 2 Years

Speed : 80m/min

Usage : Making Corrugated Cardboard

Function : cardboard making production line

Color : Customized Color

Driven type : Electric

Contact Now

YK-280S Fingerless Type Single Facer For 2 Ply Corrugated Cardboard Production Line

Structural features:

1.corrugated roller material adopt 48CrMo Alloy steel.

2.pressure roller ¢ 284mm,surface grinding and chrome-plated; cylinder control and remove up and down

3.pneumatic control glue to glue back, glue roller diameter ￠215mm,Engraved polished surface after a 36-line pit style textured machined chrome plated,after scraping the roller surface polished hard chrome plated.

regular technical parameters:

1.effective width:1600mm 2.operation direction:left or right(determined in accordance with customer plant)

3.design speed:100m/min working speed:60m/min

4.temperature range:200—260℃

5.corrugated flute:(UV type or UVV type)

main purchased parts,materials and place of origin:

Name of main parts	Brands or place of origin	Material and type
Wall and Pedestals	Production own	HT200
Rotary joints and metal hoses	Shan dong teng zhou luguanqiu
Main drive motor	Hebei Hengshui	7.5Kwspeed motor
bearing	HRB,ZWZ,CYC or Zhengjiang wanxiang
Seat belt bearing	Zhengjiang five rings
High pressure air	Shanghai Yingfa
cylinder	Zhengjiang Sanzheng
contacts	Chint or de li xi

YK-280S Fingerless Type Single Facer For 2 Ply Corrugated Cardboard Production Line
