YK-SF280 Single Facer With Alloy Steel Corrugated Roller 48 CrMo

Product Categories

CHINA YIKE GROUP CO.,LTD

Contact Now

Name: YKSF280 Single Facer With Alloy Steel Corrugated Roller 48 CrMo
Brand: YIKE GROUP
Price: 1 USD

Brand Name : YIKE GROUP

Model Number : YK-280S

Certification : ISO,CE

Place of Origin : CHINA

MOQ : 1 Set Single Facer

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50 Sets Per Month

Delivery Time : 30 Days After Deposit of Single Facer

Packaging Details : Plastic Film,FCL

Voltage : according to your request

Condition : New Single Facer

After-sales service provided : Engineers available to service machinery overseas,Video technical support,Field maintenance and repair service

Type : Packaging Line

Automatic grade : Semi-Automatic

Driven type : Electric Single Facer

Color : according to your request

Warranty : 1 Year

Contact Now

roller diameters parameters:

1,diameter of corrugated roller: ￠280mm

2,diameter of pressure roller: ￠284mm

3,diameter of glue roller: ￠216mm

4,diameter of preheat roller: ￠320mm

powered motor parameters:

1,main drive motor:7.5Kw rated voltage:380V 50Hz Continuous (S1) working standard

2,suction motor:7.5Kw rated voltage:380V 50Hz Continuous (S1) working standard

main purchased parts,materials and place of origin:

Name of main parts	Brands or place of origin	Material and type
Wall and Pedestals	Production own	HT200
Rotary joints and metal hoses	Shan dong teng zhou luguanqiu
Main drive motor	Hebei Hengshui	7.5Kwspeed motor
bearing	HRB,ZWZ,CYC or Zhengjiang wanxiang
Seat belt bearing	Zhengjiang five rings
High pressure air	Shanghai Yingfa
cylinder	Zhengjiang Sanzheng
contacts	Chint or de li xi

YK-SF280 Single Facer With Alloy Steel Corrugated Roller 48 CrMo
